These cutting-edge relay modules are incredibly compact with a width of only 6.4mm and a low height, making them a perfect fit for any low cabinet box. Another game-changing feature is the ability to customize them for space-saving needs in applications that require a normally open contact version or a fused relay output version. With TERMSERIES-COMPACT, there’s no longer a need for extra terminal blocks with fuses.

Ultra-compact with a slim, flat design, these relays can be installed anywhere, even in environments with strong vibrations. Since they have the same contours as the tried-and-tested TERMSERIES family, all the accessories of the series can be used for applications such as cross-connections.

“TERMSERIES-COMPACT modules save on components, simplify wiring, and significantly cut down assembly time,” said Carlus Hicks, Director-Cabinet Products Division. “Our patented PUSH-IN connection technology and colored pushers make wiring 75% faster and considerably safer.”

Hicks also noted that TERMSERIES-COMPACT come in different versions and a variety of input voltages wit 24-230 V UC and 12-80 V UC available for the first time in an extremely compact design. “As a highly flexible connectivity module that’s compatible with the complete TERMSERIES family, TERMSERIES-COMPACT is destined to become the preferred solution for interfacing loads, sensors or signals to different PLC and DCS systems for our industry partners,” he added.

Learn more about Weidmuller’s new line of TERMSERIES-COMPACT modules.
